AMD is one of the best graphics card manufacturers in this current world. The Radeon series is one of their very powerful graphics cards, which will drive you into a digital world. Powerful gaming, High-resolution work, and Various design work is very easy when you have the AMD Radeon series.
- Powerful Gaming
- Direct X 11
- HD videos
- 2 GHz Memory.
Let’s have a good look at the full specification:-
- 1000MHz Engine Clock
- 2GB GDDR5 Memory
- 1200MHz Memory Clock (4.8 Gbps GDDR5)
- 153.6GB/s memory bandwidth (maximum)
- 2.56 TFLOPS Single Precision compute power
GCN Architecture
- 20 Compute Units (1280 Stream Processors)
- 80 Texture Units
- 128 Z/Stencil ROP Units
- 32 Color ROP Units
- Dual Geometry Engines
Dual Asynchronous Compute Engines (ACE)
- 256-bit GDDR5 memory interface
- PCI Express 3.0 x16 bus interface
- DirectX® 11.1-capable graphics
- OpenGL 4.2 support
- Partially Resident Textures (PRT)
- Ultra-high resolution texture streaming technology
Image quality enhancement technology
- Up to 24x multi-sample and super-sample anti-aliasing
- Adaptive anti-aliasing
- Morphological Anti-Aliasing (MLAA)
- Enhanced Quality Anti-Aliasing (EQAA)
- DirectX® 9/10/11 Supersample Anti-Aliasing (SSAA)
- Requires AMD Catalyst™ 12.2 or later
- 16x angle independent anisotropic texture filtering
AMD Eyefinity multi-display technology
- Up to 6 displays supported
- Independent resolutions, refresh rates, color controls, and video overlays
- Display grouping.
Combine multiple displays to behave like a single large display
- Discrete Digital Multi-Point Audio (DDMA)
AMD App Acceleration
- Supports OpenCL™ 1.2, DirectCompute 11 & Microsoft C++ AMP
- Double Precision Floating Point
- AMD HD Media Accelerator
Unified Video Decoder (UVD)
- H.264
- VC-1
- MPEG-2 (SD & HD)
- MVC (Blu-ray 3D)
- MPEG-4 Part 2 (DivX/Xvid)
- Adobe Flash
- DXVA 1.0 & 2.0 support
Enhanced Video Quality features
- Advanced post-processing and scaling
- Deblocking
- Denoising
- Automatic deinterlacing
- Mosquito noise reduction
- Edge enhancement
- 3:2 pulldown detection
Advanced video color correction
Brighter whites processing (Blue Stretch)
Independent video gamma control
Flesh tone correction
Color vibrance control
Dynamic contrast
Brighter whites processing (Blue Stretch)
Independent video gamma control
Flesh tone correction
Color vibrance control
Dynamic contrast
Dynamic video range control
- AMD HD3D technology3
Stereoscopic 3D display/glasses support
Blu-ray 3D support
Stereoscopic 3D gaming
3rd party Stereoscopic 3D middleware software support
Blu-ray 3D support
Stereoscopic 3D gaming
3rd party Stereoscopic 3D middleware software support
- AMD CrossFire™ multi-GPU technology
Dual, triple or quad-GPU scaling
AMD CrossFire™ multi-GPU technology
Cutting-edge integrated display support
Supports dual-GPU performance scaling
DisplayPort 1.2
Max resolution: 4096×2160 per display
Multi-Stream Transport
21.6 Gbps bandwidth
High bit-rate audio
Quad HD/4k video support
AMD CrossFire™ multi-GPU technology
Cutting-edge integrated display support
Supports dual-GPU performance scaling
DisplayPort 1.2
Max resolution: 4096×2160 per display
Multi-Stream Transport
21.6 Gbps bandwidth
High bit-rate audio
Quad HD/4k video support
1080p60 Stereoscopic 3D
HDMI® (With 4k, 3D, 3GHz, Deep Color and x.v.Color™)
HDMI® (With 4k, 3D, 3GHz, Deep Color and x.v.Color™)
Max resolution: 4096×2160
1600p60 Stereoscopic 3D
1600p60 Stereoscopic 3D
Quad HD/4k video support
Dual-link DVI with HDCP
Max resolution: 2560×1600
VGA: Max resolution: 2048×1536
Dual-link DVI with HDCP
Max resolution: 2560×1600
VGA: Max resolution: 2048×1536
Integrated HD audio controller
- Output protected high bit rate 7.1 channel surround sound over HDMI with no additional cables required
- Supports AC-3, AAC, Dolby TrueHD and DTS Master Audio formats
AMD PowerPlay™ power management technology4
- Automatic power management with low power idle states
AMD PowerTune technology
- Intelligent TDP management technology
- Dynamic clockspeed/performance enhancement for games
AMD ZeroCore Power technology
- Ultra-low idle power when the connected display is in power saving mode
- Efficient low power mode for desktop work
- Secondary GPUs in an AMD CrossFire™ technology configuration power down when unneeded
AMD Catalyst™ graphics and HD video configuration software
- Software support for Windows 7, Windows Vista and Windows XP
- AMD Catalyst™ Control Center – AMD Catalyst™ software application and user interface for setup, configuration, and accessing features of AMD Radeon products.
- Unified Graphics display driver – AMD Catalyst™ software enabling other PC programs and devices to use advanced graphics, video, and features of AMD Radeon™ products.
System Reqs
- PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard
- 500W (or greater) power supply with one 75W 6-pin PCI Express power connector recommended
- 600W power supply (or greater) with four 75W 6-pin PCI Express power connectors recommended for AMD CrossFire™ technology.
- Certified power supplies are recommended. Refer to http://ati.amd.com/certifiedPSU for a list of Certified products
- Minimum 4GB of system memory
- 8GB (or more) of system memory recommended for AMD CrossFire™ technology
- Installation software requires CD-ROM drive, a keyboard, a mouse, and a display
- DVD playback requires DVD drive and a DVD
- Blu-ray™ playback requires Blu-ray drive and a Blu-ray disc
- For an AMD CrossFire™ system, a second AMD Radeon™ HD 7770 GPU, an AMD CrossFire™ Ready motherboard and one AMD CrossFire™ Bridge Interconnect cable is required
- Use of 3 or more displays with AMD Eyefinity technology requires a DisplayPort-capable panel or an AMD Eyefinity validated dongle. See http://www.amd.com/EyefinityDongles for a list of validated DisplayPort dongles.
- 64-bit operating system highly recommended
- Not for industrial or commercial use. See AMD FirePro™ Graphics solutions for these applications.
